TGS205-P SSD

High-Endurance Industrial mSATA SSD, Delivering Exceptional Durability with pSLC Technology

mSATA SSD
Wide-Temperature Operation
65,000 P/E Cycles
  • Capacity
    8 GB16 GB32 GB64 GB
  • Flash Type
    3D TLC
  • Operating Temperature
    -40°C to +85°C

Overview

BIWIN TGS205-P SSD is built for demanding industrial applications, integrating industrial-grade controllers and TLC NAND flash technology. It is widely used in industrial control, rail transportation, data communication, and other fields, and is compatible with critical equipment such as automation devices, metro gate systems, and communication base stations.

The TGS205-P SSD uses a M.2 2242 form factor and strictly adheres to the SATA III protocol standard, providing high-speed performance with sequential read and write speeds up to 560 MB/s and 510 MB/s. With an operating temperature range from -40°C to +85°C, it ensures stable operation in extreme environments and offers capacities ranging from 8 GB to 64 GB for diverse storage requirements.

It employs Pseudo SLC (pSLC) technology, leveraging BIWIN’s innovative flash optimization algorithms to overcome the lifespan limitations of traditional TLC, providing enhanced durability. The SSD includes various customization options, such as conformal coating for added protection, sidefill/underfill processes to improve vibration and shock resistance, and anti-sulfurization design to protect against environmental degradation. The TGS205-P SSD follows BIWIN’s proprietary industrial-grade testing standards, ensuring exceptional reliability and safety.

  • 01

    Stable Wide-Temperature Operation from -40°C to +85°C

    The BIWIN TGS205-P SSD ensures reliable operation in extreme conditions, with advanced selection mechanisms that guarantee the flash memory, controller, and components support a wide temperature range of -40°C to +85°C. Coupled with our proprietary firmware enhancement strategy, it ensures stable performance in challenging climates and harsh industrial environments.
  • 02

    65,000 P/E Cycles for Exceptional Longevity and Cost-Effectiveness

    Leveraging BIWIN’s proprietary flash optimization algorithms and pSLC technology, the TGS205-P SSD offers outstanding performance with up to 65,000 P/E cycles, nearly 22 times the endurance of conventional 3D TLC NAND flash (which typically supports only 3,000 P/E cycles). This high endurance, coupled with cost efficiency, provides the optimal solution for industrial control applications that require long-lasting performance while minimizing overall costs.
  • 03

    Advanced Technologies to Extend Product Lifespan

    The BIWIN TGS205-P SSD incorporates technologies such as dynamic/static wear leveling, bad block management, TRIM, and garbage collection, ensuring optimal utilization of NAND Flash and significantly enhancing the product’s durability.
  • 04

    Rigorous Testing for Exceptional Quality

    The BIWIN TGS205-P SSD undergoes extensive testing, including “Double 85 test” (85℃ high temperature and 85% high humidity), rapid temperature cycling (10℃/min), high/low-temperature stress testing, and anti-sulfuration G3 standards. With an MTBF (Mean Time Between Failures) exceeding 3 million hours, this SSD offers outstanding reliability.
  • 05

    Flexible Customization to Meet Specialized Application Needs

    Various customization options, including conformal coating, sidefill/underfill, anti-sulfuration, and metal/graphene heatsinks, can offer comprehensive solutions to meet specific customer requirements.

  • S.M.A.R.T.

  • Firmware Update

  • End-to-End Data Protection

  • Data Erasure

  • Garbage Collection

  • Dynamic/Static Wear Leveling

  • TRIM Command

  • Bad Block Management

  • Intelligent Thermal Throttling

  • Network Communications

    Network Communications

  • Industrial Automation

    Industrial Automation

  • Security Surveillance

    Security Surveillance

  • Intelligent Transportation

    Intelligent Transportation

  • Smart Energy

    Smart Energy

Specifications

Latest Update: 2025/08/27
Product Line
SSD
Product Grade
Industrial Wide-temp
Model Name
TGS205-P
Interface
SATA III
Form Factor
M.2 2242
Flash Type
3D TLC
Firmware
pSLC
DRAM Cache
DRAM-less
Capacity
8 GB
16 GB
32 GB
64 GB
Sequential Read (Up to)
560 MB/s
Sequential Write (Up to)
510 MB/s
Random Read 4K (Up to)
90K IOPS
Random Write 4K (Up to)
70K IOPS
Read Power Consumption (Max.)
0.69 W
Write Power Consumption (Max.)
0.78 W
Idle Power Consumption (Max.)
0.2 W
Dimensions
42.00 x 22.00 x 3.60 mm
Operating Temperature
-40°C to +85°C
Storage Temperature
-55°C to +95°C
Endurance
65000 P/E cycles
MTBF
>3,000,000 hours
Certifications
CE, FCC, RoHS, HF, REACH
TBW (Up to)
1500 TBW
Warranty
5-Year Limited

Order Information

Capacity

8 GB
16 GB
32 GB
64 GB

Part Number

TG42B00820Y0P
TG42B01620Y0P
TG42B03220Y0P
TG42B06420Y0P

Power Loss Protection

Firmware-Based
Firmware-Based
Firmware-Based
Firmware-Based
1. Tested by BIWIN labs. Actual performance may vary due to systems, devices, or environment.
2. Maintenance and future updates are required throughout the product lifecycle. Specifications are subject to change without notice.
3. The pictures are for illustration only. Actual products may vary due to product enhancements or changes.
4. Not all products are sold in all regions of the world.
5. As used for storage capacity, one megabyte (MB)= one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on the operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabyte per second (GB/s) = one billion bytes per second.
6. MTBF = Mean Time Between Failures based on internal testing using the Telcordia stress testing standard.
7. Please visit www.biwintechnology.com for warranty details in your region.
8. For more information, please contact sales@biwintech.com.
