TAE208 Automotive eMMC 5.1

High-Performance, Automotive-Grade eMMC with 3D TLC NAND, Reliable, Fast Data Storage

eMMC 5.1 Standard
AEC-Q100 Compliance
Durable in Harsh Conditions
  • Capacity
    64 GB128 GB
  • Flash Type
    3D TLC
  • Operating Temperature
    -40°C to +105°C

Overview

The BIWIN TAE208, with the eMMC 5.1 standard for automotive-grade performance, is built with high-quality 3D TLC NAND. It’s designed for a wide range of in-vehicle applications, including intelligent cockpit systems, in-vehicle infotainment (IVI), central control units, navigation, digital instrument clusters, T-BOX modules, and domain controllers.
Supporting HS400 high-speed mode, the TAE208 also features FFU, Boot Partition, RPMB, and idle data acceleration to optimize performance. Housed in a compact BGA package, the TAE208 offers capacities up to 128 GB, providing a high-density solution for space-constrained automotive designs.
To withstand the harsh conditions of vehicle environments, the TAE208 supports an operating temperature range of -40°C to +105°C, fully compliant with AEC-Q100 Grade 2 standards. The BIWIN TAE208 eMMC meets the stringent demands of automotive systems and offers an impressive combination of high endurance, low power consumption, high bandwidth, and long-term reliability.

  • 01

    High Performance with AEC-Q100 Compliance

    BIWIN TAE208 eMMC strictly adheres to the eMMC 5.1 standard and is AEC-Q100 qualified. It supports HS400 high-speed mode, delivering faster data transfer rates to meet the demands of complex environments, including smart cockpit features and autonomous driving.
  • 02

    Large Capacity, Versatile Storage

    The BIWIN TAE208 eMMC utilizes 3D TLC NAND technology to deliver stable, reliable storage while offering cost efficiency. With a maximum capacity of 128 GB, it is designed to meet the extensive data storage needs of modern automotive systems, including intelligent cockpit features, central control units, and navigation systems.
  • 03

    Data Integrity and Protection

    The BIWIN TAE208 eMMC features a Boot Partition to ensure reliable and secure system booting. The RPMB (Replay Protected Memory Block) enables encrypted storage to protect user privacy, while the idle data acceleration feature further optimizes system performance, increasing response speed.
  • 04

    High Durability, Stable Operation

    The BIWIN TAE208 eMMC meets the Automotive Grade 2 temperature standards, operating within a range of -40°C to +105°C. This ensures exceptional durability and consistent performance in extreme environmental conditions. Designed to withstand high vibration, humidity, and other challenging factors, it is the ideal solution for automotive applications that demand stable operation in harsh environments.

  • Bad Block Management

  • Power Loss Protection

  • Global Wear Leveling

  • RPMB Partition (Replay Protected Memory Block)

  • FFU (Firmware Field Upgrade)

  • ECC (Error Correction Code)

  • Smart Cockpit

    Smart Cockpit

  • IVI

    IVI

  • Central Control

    Central Control

  • Navigation

    Navigation

  • Autonomous Driving

    Autonomous Driving

  • Instrument Cluster

    Instrument Cluster

  • T-BOX

    T-BOX

  • Domain Controller

    Domain Controller

Specifications

Latest Update: 2025/08/03
Product Line
Embedded
Product Grade
Automotive
Model Name
TAE208
eMMC Standard
eMMC 5.1
Flash Type
3D TLC
Capacity
64 GB
128 GB
Sequential Read (Up to)
330 MB/s
Sequential Write (Up to)
220 MB/s
Operation Current (Max.)
175 mA
Standby Current (Max.)
120 μA
Dimensions
11.50 x 13.00 x 1.10 mm
Packaging
FBGA 153 Ball
Operating Temperature
-40°C to +105°C
Storage Temperature
-40°C to +105°C
Endurance
3000 P/E cycles
MTBF
>3,000,000 hours
Certifications
RoHS, REACH, AEC-Q100
Warranty
5-Year Limited

Order Information

Capacity

64 GB
128 GB

Part Number

BWEFMA064GN1KC
BWEFMA128GN1KC

Power Loss Protection

Firmware-Based
Firmware-Based
1. Tested by BIWIN labs. Actual performance may vary due to systems, devices, or environment.
2. Maintenance and future updates are required throughout the product lifecycle. Specifications are subject to change without notice.
3. The pictures are for illustration only. Actual products may vary due to product enhancements or changes.
4. Not all products are sold in all regions of the world.
5. As used for storage capacity, one megabyte (MB)= one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on the operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabyte per second (GB/s) = one billion bytes per second.
6. MTBF = Mean Time Between Failures based on internal testing using the Telcordia stress testing standard.
7. Please visit www.biwintechnology.com for warranty details in your region.
8. For more information, please contact sales@biwintech.com.
