Home > Products > SSD

Mini SSD

Mini Yet Powerful SSD with PCIe 4.0, Up to 3700 MB/s Read, Built for Durability and Stability

15.0 mm × 17.0 mm × 1.4 mm
Up to 3700 MB/s Read, 3400 MB/s Write
Advanced LGA Packaging
  • Capacity
    512 GB 1 TB2 TB
  • Flash Type
    3D TLC
  • Operating Temperature
    -40°C to +85°C

Overview

The BIWIN Mini SSD is a high-performance, ultra-mini storage solution designed specifically for edge AI devices and mobile computing scenarios. Leveraging a PCIe 4.0 x2 interface and NVMe 1.4 protocol, BIWIN Mini SSD achieves impressive read speeds up to 3700 MB/s and write speeds up to 3400 MB/s. With capacities ranging from 512 GB to 2 TB, the Mini SSD meets the rigorous demands of mobile devices, edge computing, and other data-intensive applications.

The Mini SSD uses advanced packaging, using LGA (Land Grid Array) packaging technology to integrate the controller and flash memory modules into a highly compact form. Measuring just 15.0 mm × 17.0 mm × 1.4 mm—approximately the size of a microSD card (about half the size of a coin), but with SSD speed and performance. Built with state-of-the-art integrated packaging technology, the Mini SSD offers excellent resistance to shocks and impacts, while its IP68-rated dust and water resistance provides an additional layer of reliability in challenging environments.

The new form factor offers a new flexibility for engineering design-in. BIWIN Mini SSD features a modular slot design, enabling plug-and-play functionality and wide compatibility with diverse devices, including laptops, tablets, smartphones, handheld gaming consoles, cameras, NAS systems, smart albums, and portable SSDs.

Widely compatible with various devices, BIWIN Mini SSD is the ideal storage companion for content creators, mobile office users, and tech enthusiasts in the smart era, enabling seamless sharing and efficient collaboration across devices.

  • 01

    Powerful PCIe 4 Performance, Ultra-Mini Form Factor

    Using advanced LGA packaging technology, the BIWIN Mini SSD measures just 15.00×17.00×1.40 mm in dimensions, with a unique form factor that saves internal space in devices such as ultrabooks and Mini PCs. Its modular slot design enables plug-and-play functionality for easy storage expansion and replacement, offering convenience and flexibility for users.
  • 02

    More Rapid Data Handling for Professional Demands

    Leveraging a PCIe 4x2 interface and NVMe 1.4 protocol, BIWIN Mini SSD delivers sequential read speeds up to 3700 MB/s and write speeds up to 3400 MB/s. Whether running AI training tasks, editing 4K video, or executing large applications, it provides excellent performance, minimizing latency and stuttering for a smoother experience.
  • 03

    Stable, Reliable, and Comprehensive Protection

    The Mini SSD features exceptional physical durability, with IP68-rated dustproof and waterproof protection, and can withstand 3-meter drops. Its integrated hardware and firmware design ensures data integrity and stability, even in challenging conditions such as vibrations and humidity, offering users reliable, all-around protection and peace of mind.

  • Dynamic SLC Cache

  • Global Wear Leveling

  • TRIM Command

  • Garbage Collection

  • Intelligent Thermal Throttling

  • Intelligent Low-Power Management

  • HMB

  • S.M.A.R.T.

  • Ultrabook

    Ultrabook

  • Handheld Gaming Console

    Handheld Gaming Console

  • NAS

    NAS

  • Smart Photo Album

    Smart Photo Album

  • Mini PC

    Mini PC

Specifications

Latest Update: 2025/08/28
Product Line
SSD
Product Grade
Consumer
Model Name
Mini SSD
Interface
PCIe Gen4x2, NVMe 1.4
Flash Type
3D TLC
DRAM Cache
DRAM-less
Capacity
1 TB
2 TB
512 GB
Sequential Read (Up to)
3700 MB/s
Sequential Write (Up to)
3400 MB/s
Random Read 4K (Up to)
550K IOPS
Random Write 4K (Up to)
650K IOPS
Read Power Consumption (Max.)
2.3 W
Write Power Consumption (Max.)
2.3 W
Idle Power Consumption (Max.)
60 mW
Low Power Consumption (PS4)
6 mW
Dimensions
15.00 x 17.00 x 1.40 mm (Max.)
Operating Temperature
0°C to +70°C
Storage Temperature
-40°C to +85°C
MTBF
>1,500,000 hours
Certifications
RoHS
TBW (Up to)
1500 TBW
Warranty
3-Year Limited

Order Information

Capacity

512 GB
1 TB
2 TB

Part Number

BL100512G-RCX
BL10001TB-RCX
BL10002TB-RCX
1. Tested by BIWIN labs. Actual performance may vary due to systems, devices, or environment.
2. Maintenance and future updates are required throughout the product lifecycle. Specifications are subject to change without notice.
3. The pictures are for illustration only. Actual products may vary due to product enhancements or changes.
4. Not all products are sold in all regions of the world.
5. As used for storage capacity, one megabyte (MB)= one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on the operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabyte per second (GB/s) = one billion bytes per second.
6. MTBF = Mean Time Between Failures based on internal testing using the Telcordia stress testing standard.
7. Please visit www.biwintechnology.com for warranty details in your region.
8. For more information, please contact sales@biwintech.com.

Documents

All Types

  • All Types
  • Specifications
Type
Title
Date
 Operate
Specifications BIWIN Mini SSD Specifications 2025-09-03 Download
