DDR5 SODIMM

Low-Power DDR5 Memory with High Speed, Enhanced Reliability, and Optimized Bandwidth Efficiency

Data Rate Up to 5600 MT/s
Low Power Consumption
Dual 32-Bit Sub-Channels
  • Capacity
    16 GB 32 GB
  • Data Rate
    4800 MT/s5600 MT/s
  • Operating Temperature
    0°C to +85°C

Overview

BIWIN DDR5 SODIMM is a high-performance, low-power, 262-pin memory module fully compliant with JEDEC DDR5 specifications. Operating at 1.1 V, it delivers data transfer rates up to 5600 MT/s, offering a significant performance improvement while maintaining energy efficiency. The module supports an operating temperature range of 0°C to 85°C for reliability across varied environments. Built with premium ICs for excellent compatibility and long-term stability. The module integrates advanced features, including on-die ECC for error correction, an onboard PMIC (Power Management IC) for improved power integrity, and an internal temperature sensor for real-time thermal monitoring. BIWIN DDR5 SODIMM is ideal for demanding applications, including high-performance laptops and gaming notebooks, mini PCs, all-in-one systems, mobile workstations, network-attached storage, and embedded systems.

  • 01

    High-Quality Components for High-Speed, Stable Operation

    BIWIN DDR5 SODIMM uses premium ICs for consistent quality and high-speed performance. With data rates up to 5600 MT/s, this SODIMM delivers stable operation and excellent compatibility across platforms.
  • 02

    Low Power Consumption with Enhanced Thermal Management

    Operating at a low voltage of 1.1 V, the module is optimized for energy efficiency in high-frequency applications. The onboard Power Management IC (PMIC) enhances power signal integrity, while the onboard SPD hub includes a built-in temperature sensor for real-time thermal monitoring and improved reliability.
  • 03

    Dual-Channel Architecture for Higher Bandwidth Efficiency

    Available in 4800 MT/s and 5600 MT/s data rates, BIWIN DDR5 SODIMM is designed with dual 32-bit sub-channels, double burst length, and support for Same-Bank Refresh commands. These architectural enhancements significantly improve data throughput, boosting performance in multi-tasking, and high-load workloads.
  • 04

    On-Die ECC with Extensive Validation for Data Integrity

    BIWIN DDR5 SODIMM supports on-die ECC for real-time detection and correction of single-bit errors, reducing the risk of system crashes. Each module also undergoes strict quality control and testing to provide long-term reliability in high-performance computing environments.

  • 1.Underfill

  • Sidefill

  • 30μ" Gold Finger

  • Anti-Sulfuration

  • Laptop

    Laptop

  • Mini PC

    Mini PC

  • All-in-One PC

    All-in-One PC

  • Compact Workstation PC

    Compact Workstation PC

  • High-Speed Network Storage System

    High-Speed Network Storage System

  • Embedded System

    Embedded System

Specifications

Latest Update: 2025/09/27
Product Line
DRAM Module
Product Grade
Consumer
Model Name
DDR5 SODIMM
DIMM Type
DDR5 SODIMM
Capacity
16 GB
32 GB
Data Rate
4800 MT/s, 5600 MT/s
Pin
262 Pin
Voltage
1.1 V
PCB Gold Finger Thickness
3 µ" / 30 µ"
Anti-Sulfuration Protection
Customizable
Dimensions
69.60 x 30.00 x 3.70 mm
Operating Temperature
0°C to +85 °C
Storage Temperature
-55°C to +100°C
Certifications
RoHS, CE, FCC
Warranty
3-Year Limited
1. Tested by BIWIN labs. Actual performance may vary due to systems, devices, or environment.
2. Maintenance and future updates are required throughout the product lifecycle. Specifications are subject to change without notice.
3. The pictures are for illustration only. Actual products may vary due to product enhancements or changes.
4. Not all products are sold in all regions of the world.
5. Please visit www.biwintechnology.com for warranty details in your region.
6. For more information, please contact sales@biwintech.com.
