TGP203 SSD

Wide-Temperature Industrial SSD, Reliable PCIe Gen3x4 Performance for Mission-Critical Applications

PCIe Gen3x4, NVMe 1.4
Up to 3400 MB/s Read
Wide-Temperature Operation
  • Capacity
    64 GB 128 GB256 GB512 GB1 TB2 TB
  • Flash Type
    Industrial 3D TLC
  • Operating Temperature
    -40℃ to +85℃

Overview

For industrial-grade applications, the BIWIN TGP203 SSD delivers high reliability and performance in sectors including industrial control, rail transportation, and data communications. It is ideal for key systems such as automation equipment, subway gate systems, and communication base stations.

Built with an M.2 2280 form factor, PCIe Gen3x4 interface, and NVMe 1.4 protocol, the TGP203 offers sequential read speeds up to 3400 MB/s and write speeds up to 2800 MB/s for more efficient data processing. Available in capacities from 64 GB to 2 TB, it operates across a wide temperature range of -40℃ to 85℃, guaranteeing stability even in extreme environments.

The TGP203 adheres to BIWIN’s rigorous industrial standards, ensuring exceptional reliability. It also includes power-loss protection, safeguarding data during unexpected power outages. Additionally, the TGP203 offers customizable features such as conformal coating, underfill/sidefill, and anti-sulfurization protection, providing a choice of comprehensive solutions for industrial applications requiring high security, durability, and long-term performance.

  • 01

    High-Speed Data Transfer with PCIe Gen3x4

    The TGP203 uses a high-performance PCIe Gen3x4 interface, compliant with NVMe 1.4. It delivers sequential read speeds up to 3400 MB/s and write speeds up to 2800 MB/s, with random read/write performance reaching 360K/230K IOPS.
  • 02

    Stable Operation Even Across Wide Temperature Ranges

    With BIWIN’s advanced manufacturing process, the TGP203 ensures that the flash memory, controller, and components perform stably within a wide temperature range of -40℃ to +85℃. Paired with proprietary firmware-based thermal optimization, it guarantees stable performance even in extreme industrial conditions.
  • 03

    Dual Power-Loss Protection for Enhanced Stability

    BIWIN TGP203 features both firmware-based and hardware-based power loss protection for more stable power management. In the event of unexpected power interruptions, the TGP203 allows additional time to store volatile data, protecting data integrity and minimizing any risk of data loss.
  • 04

    Extended Lifespan with Advanced Technologies

    Supporting features such as dynamic/static wear leveling, bad block management, TRIM, and garbage collection, the TGP203 offers optimal use of NAND flash and significantly enhances product durability.
  • 05

    Rigorous Testing for Premium Reliability

    The BIWIN TGP203 undergoes stringent testing, including “Double 85” (85℃ high temperature and 85% high humidity test), rapid temperature cycling (10℃/min), high/low-temperature stress testing, and anti-sulfuration G3 standards. With an MTBF of more than 3 million hours, it brings exceptional reliability to any operation.
  • 06

    Customizable Solutions for Specialized Needs

    The TGP203 offers custom services such as conformal coating, sidefill/underfill, anti-sulfurization protection, and metal/graphene heatsinks, significantly enhancing reliability and durability under specific application requirements.

  • Power Loss Protection

  • S.M.A.R.T.

  • Online Firmware Update

  • End-to-End Data Protection

  • Data Erasure

  • Garbage Collection

  • Dynamic/Static Wear Leveling

  • TRIM Command

  • Bad Block Management

  • Intelligent Thermal Throttling

  • Network Communications

    Network Communications

  • Industrial Automation

    Industrial Automation

  • Security Surveillance

    Security Surveillance

  • Rail Transportation

    Rail Transportation

  • Smart Energy

    Smart Energy

Specifications

Latest Update: 2025/08/03
Product Line
SSD
Product Grade
Industrial Wide-temp
Model Name
TGP203
Interface
PCIe Gen3x4, NVMe 1.4
Form Factor
M.2 2280
Flash Type
Industrial 3D TLC
Firmware
TLC Direct Write
DRAM Cache
DRAM-less
Capacity
1 TB
2 TB
64 GB
128 GB
256 GB
512 GB
Sequential Read (Up to)
3400 MB/s
Sequential Write (Up to)
2800 MB/s
Random Read 4K (Up to)
360K IOPS
Random Write 4K (Up to)
230K IOPS
Read Power Consumption (Max.)
1.54 W
Write Power Consumption (Max.)
3.1 W
Idle Power Consumption (Max.)
51 mW
Dimensions
22.00 x 80.00 x 3.60 mm
Operating Temperature
-40°C to +85°C
Storage Temperature
-55°C to +95°C
Endurance
3000 P/E cycles
MTBF
>3,000,000 hours
Certifications
CE, FCC, RoHS, HF, REACH
TBW (Up to)
2000 TBW
Warranty
3-Year Limited

Order Information

Capacity

64 GB
128 GB
256 GB
512 GB
1 TB
2 TB
64 GB
128 GB
256 GB
512 GB
1 TB
2 TB

Part Number

TG80G06430Y0TP0
TG80G12830Y0TP0
TG80G25630Y0TP0
TG80G51230Y0TP0
TG80G1T230Y0TP0
TG80G2T230Y0TP0
TG80G06430Y0T
TG80G12830Y0T
TG80G25630Y0T
TG80G51230Y0T
TG80G1T230Y0T
TG80G2T230Y0T

Power Loss Protection

Hardware + Firmware-Based
Hardware + Firmware-Based
Hardware + Firmware-Based
Hardware + Firmware-Based
Hardware + Firmware-Based
Hardware + Firmware-Based
Firmware-Based
Firmware-Based
Firmware-Based
Firmware-Based
Firmware-Based
Firmware-Based
1. Tested by BIWIN labs. Actual performance may vary due to systems, devices, or environment.
2. Maintenance and future updates are required throughout the product life cycle. Specifications are subject to change without notice.
3. The pictures are for illustration only. Actual products may vary due to product enhancements or changes.
4. Not all products are sold in all regions of the world.
5. As used for storage capacity, one megabyte (MB)= one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on the operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576 bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabyte per second (GB/s) = one billion bytes per second.
6. MTBF = Mean Time Between Failures based on internal testing using the Telcordia stress testing standard.
7. Please visit www.biwintechnology.com for warranty details in your region.
8. For more information, please contact sales@biwintech.com.
